Overshooting Tops RGB
Main applications
- 24-hour monitoring of overshooting tops.
- This RGB is a variant of the basic Airmass RGB. It differs in the selected ranges and in the channel difference applied in the red component.
RGB Recipes by Satellite Instrument
MSG SEVIRI Overshooting Tops RGB
| Colour beam |
Channel (difference) |
Range min |
Range max |
Unit |
Gamma |
| Red |
WV6.2 -- IR10.8 |
-25 |
+5 |
K |
1.0 |
| Green |
IR9.7 -- IR10.8 |
-30 |
+25 |
K |
1.0 |
| Blue |
WV6.2 |
243 |
190 |
K |
1.0 |
MTG FCI Overshooting Tops RGB
| Colour beam |
Channel (difference) |
Range min |
Range max |
Unit |
Gamma |
| Red |
WV6.3 -- IR10.5 |
-23.8 |
+6.4 |
K |
1.0 |
| Green |
IR9.7 -- IR10.5 |
-29.9 |
+23.6 |
K |
1.0 |
| Blue |
WV6.3 |
244.5 |
191.4 |
K |
1.0 |
